1530-3KW Large Surround Exchange Platform Laser Cutting Machine
- Industrial Grade High-Efficiency Laser Cutting Solution
Product Overview of the fiber laser cutting machine:
The 1530-3KW Large Surround Exchange Platform Laser Cutting Machine is a high-power, high-efficiency CNC laser cutting equipment suitable for sheet metal processing, machinery manufacturing, automobile manufacturing, aerospace and other fields. It uses a 3kW fiber laser and is equipped with a dual exchange worktable to achieve seamless loading and unloading, greatly improving production efficiency. The equipment adopts a fully enclosed large surround structure to ensure safe operation and environmental protection (compliant with CE standards), while providing high-precision and high-stability cutting capabilities.
Laser cutting machine core highlights:
1. High-power laser cutting machine, suitable for a variety of materials
Equipped with a 3kW high-power fiber laser, it can efficiently cut a variety of metal plates such as carbon steel, stainless steel, aluminum alloy, brass, etc.
Carbon steel (Q235): can cut up to 20mm (high-quality cut surface can reach 13mm).
Stainless steel (304): can cut up to 12mm (high-quality cut surface can reach 8mm).
Aluminum alloy: can cut up to 10mm (nitrogen cutting, no oxide layer).
2. The laser cutting machine is equipped with a double exchange worktable to achieve continuous production
The double worktables are automatically exchanged (1500×3000mm). While one worktable is processing, the other can load and unload materials, ensuring 24-hour uninterrupted production.
Driven by a servo motor, the table change time only takes 15 seconds, which is more than 50% more efficient than single-table equipment.
3. The laser cutting machine is equipped with a high-precision CNC system for stability and reliability.
The Bochu 2000E control system supports automatic focus, automatic edge detection, and dynamic compensation, ensuring cutting accuracy of ±0.05mm.
The imported linear guides and rack-and-pinion drive system achieve speeds of up to 120m/min and accelerations of 1.5G, making it suitable for high-speed precision machining.
4. The laser cutting machine features a large enclosure for safety and environmental protection.
A fully enclosed protective cover prevents leakage of laser radiation and complies with international safety standards (CE/ISO).
A dust extraction system and fume extraction device effectively collect cutting fumes, maintaining a clean working environment.
5. The laser cutting machine is equipped with intelligent automation integration (optional).
Automatic loading and unloading system: Can be connected to a robot or material storage system for unmanned production.
Vision positioning system: Automatically identifies sheet metal position, suitable for processing special-shaped parts, reducing manual intervention.
Laser cutting machine technical parameters：
Model | Fiber laser cutting machine |
Working Area | 1500*3000mm |
Laser Power | 3kw |
Laser Generator | Max |
Laser Wave Length | 1064nm |
Working Table | Sawtooth-table |
Maximum Idle Running Speed | 140m/min |
Maximum acceleration | 1.5G |
Position Accuracy | ±0.02mm/m |
Repeat Positional Accuracy | ± 0.01mm |
Control System | PC control with CYPCUT |
Position Type | red dot |
Power Consumption | ≤12KW |
Working Voltage | 380V ±10 % 50/60Hz |
Auxiliary Gas | oxygen,nitrogen,air |
Working life of fiber module | More than 100000 hours |
Fiber laser cutting head | Raytools Auto focus BM110 laser cutting head |
Cooling System | Hanli industrial water chiller |
Work Environment | 0-45°C, Moisture 45-85% |
Delivery time | 25 working days |
Fiber Laser cutting machine industry application cases
industry | Typical workpieces | Processing advantages |
Automobile Manufacturing | Chassis bracket, exhaust pipe, door sheet metal | 3KW high power can quickly cut 20mm carbon steel with high consistency |
Mechanical equipment | Gearbox, frame, protective cover | High precision (±0.05mm) ensures assembly fit |
Elevator industry | Car wall panels, guide rail brackets | Large tabletop whole plate cutting to reduce splicing welds |
Kitchen and bathroom appliances | Stainless steel panel, range hood housing | Burr-free cutting reduces subsequent grinding processes |
Why choose our 1530-3KW Fiber laser cutting machine?
✔ Technical Standards - Core components (laser, guide rails, control system) are all imported brands, ensuring stability and durability.
✔ 24/7 Continuous Production - Interchangeable platform + 3KW high power, suitable for high-volume OEM factories.
✔ Energy-saving and Environmentally Friendly - 40% less energy than traditional CO2 laser machines, fiber lasers require no consumables.
✔ Customized Services - Optional automated loading and unloading, dust removal systems, and laser head cleaning devices are available.
After-Sales Service Commitment
✅ Global Warranty - 36-month warranty on core components
✅ 2-hour response - Online troubleshooting by our technical team
✅ Free Training - Operation and maintenance video tutorials provided
We don't just sell equipment; we provide a full lifecycle service solution. From installation and commissioning to equipment decommissioning, our 15-year professional team will provide comprehensive support, ensuring your production never stops.
