Discover Our High-Efficiency H-Beam Production Line – The Ultimate Solution for Structural Steel Manufacturing!
Why Choose Our H-Beam Production Line?
Our state-of-the-art H-beam production line is engineered for precision, efficiency, and durability—perfect for steel fabricators, construction firms, and industrial manufacturers. Whether you're producing beams for skyscrapers, bridges, warehouses, or industrial frameworks, our automated line delivers superior quality with unmatched productivity.
Benefits of the H-Beam Laser Production Line:
1. Fully Automated Operation – Minimize labor costs & maximize output
2.High-Speed Rolling & Welding – Produce up to 30 meters/minute
3.Adaptable to Various Sizes – From 100mm to 1000mm H-beams
4.Precision Straightening & Cutting – Guaranteed ±1mm tolerance
Advanced H-Beam Laser Cutting Machine – Technical Features:
Our gantry-style H-beam laser cutting system integrates premium components and advanced engineering to deliver unmatched precision, speed, and durability for industrial metal fabrication. Below are the key technical features that set our machine apart:
1️⃣ High-Stability Gantry Drive System
Dual-Drive Gantry Structure – Ensures balanced force distribution and eliminates deflection during high-speed operation.
Premium Imported Components – High-precision gear racks and linear guide rails minimize backlash and vibration for ultra-smooth motion (±0.03mm repeatability).
Rigid Transmission – Optimized for acceleration up to 1.5G while maintaining cutting precision at speeds up to 120m/min.
2️⃣ Ultra-Rigid Welded Bed Construction
Stress-Relieved Design – The one-piece welded steel bed undergoes annealing + vibration aging treatment, eliminating residual stress for long-term stability.
High-Precision Machining – Post-weld rough and finish machining ensures flatness within 0.05mm/m², preventing any deformation during high-dynamic cutting.
Enhanced Responsiveness – Minimized structural vibration translates to faster axis response and smoother motion transitions.
3️⃣ High-Performance Servo Drive System
Japanese-Origin Fuji Servo Motors (X/Y/Z Axes) – Deliver high torque, low inertia, and ±0.01mm positioning accuracy even under rapid acceleration.
Optimized Dynamic Control – Enables sharp cornering without speed loss, maintaining cutting quality in complex contours.
4️⃣ Dedicated Fiber Laser CNC System
Laser-Optimized OS – Features proprietary algorithms for pierce optimization, taper compensation, and real-time power adjustment.
Intuitive HMI – Supports DXF/DWG file import, nesting optimization, and process database for common materials (carbon steel, stainless steel, aluminum).
Smart Monitoring – Includes cutting head collision detection, gas pressure feedback, and beam calibration tools.
5️⃣ Precision Cutting Head & Sensing
High-Sensitivity Capacitive Sensor – Auto-adjusts focus position (±0.1mm) and maintains consistent standoff distance, even on warped surfaces.
Industrial-Grade Fiber Laser Head – Supports 150mm+ cutting depth with auto-rotating nozzle for bevel cuts (±45°).
Crash Protection – Instant retract upon collision, preventing damage to lenses and nozzles.
6️⃣ Intelligent Gas Control System
Imported Proportional Pressure Valve – Digitally regulates O₂/N₂/air assist gases (±0.01MPa accuracy) for optimal cut quality across materials.
Dynamic Pressure Adjustment – Automatically adapts gas flow based on thickness and cutting speed.
Equipment Configuration of the H beam Laser cutting machine:
Serial number | Name | Brand |
1 | Y-axis servo motor (×2 units) | Bochu Servo |
2 | X-axis servo motor | Bochu Servo |
3 | Z-axis servo motor (with brake) | Bochu Servo |
4 | Reducer (flange connection) | French Modoli |
5 | Guide | Taiwan Ketai |
6 | YYC 6-grade high-precision ground rack | Taiwan YYC |
7 | Fiber Laser | MAX 20000w |
8 | Bochu FSCUT CNC cutting system | Shanghai Bochu 9200 |
9 | BC axis | Shanghai Bochu |
10 | Laser cutting head | Black Diamond 462P pointed |
1 1 | Hanli laser dedicated water cooling machine (dual temperature and dual control) | Wuhan Hanli |
12 | Table effective cutting XYZ | 5000mm 32000mm 1500mm |
Remark | ||
After-sales Service of the fiber laser cutting machine:
1. Warranty period: From the date of product acceptance , the warranty period is 2 years for the whole machine and 3 years for the transmitter. The full set of optical lenses is not covered by the warranty.
2. If there is a problem with the equipment, our company will quickly arrive at the customer's site to solve the problem, respond within 4 hours of customer feedback, and arrive at the customer's site within 24 hours.
3. The equipment provides lifelong maintenance, and the manufacturer only charges the cost after the warranty period.
4. Our company arranges technical personnel to conduct technical tracking at the customer's production site from time to time, conducts routine maintenance and inspection of the equipment according to the equipment usage, and answers technical questions encountered by customers during operation
